Bob's Machine Standard Jack Plate - Black Powder Coat - MW
This item is currently on backorder. You can still place an order, but it will only ship once it’s back in stock.
Bob's Machine Standard Jack Plate - Black Powder Coat Finish
This Bob's Machine Standard Jack Plate features a black powder coat finish and can support motors up to a 14.5" mounting width. For wider motors it is recommended to use the Extreme Gen3 Series. This jack plate is engineered for use with engines rated up to 300HP and over 625lbs. This unit is pre drilled for dual side mount power pole brackets.
This lightweight hydraulic jack plate is designed to keep weight off the transom. Bob's jack plates are engineered with tension rods and automotive style grease nipples in the side rails. This one piece design eliminates the need for spacers to achieve proper setback. This jack plate series has 1.5" of lift built in with an additional 6" of adjustable travel for 7.5" total lift.
The standard series jack plate is available in 4, 6, 8, 10, & 12" setbacks to suit a wide range of engines out on the market. Jack plates are an excellent way to improve an outboard's hole shot, fuel efficiency, and boat speed. Jack plates are also a great way to increase mobility in shallow waters.
Features:
- Improved fuel efficiency
- Powerful motor, able to lift heavy outboards
- 7.5" total lift
- Rated for 300hp, up to 625lb motors
- Black Powder Coat Finish
- Pre drilled for dual side mount shallow water anchor brackets
Standard Jack Plate Specifications:
| Model | Plate Weight (lbs/kgs) | Max Hp/Max Weight | Setback (in/cm) |
| 4" Standard Series | 38/17 | 300/625 | 4/10 |
| 6" Standard Series | 40/18 | 300/625 | 6/15 |
| 8" Standard Series | 45/20 | 300/625 | 8/20 |
| 10" Standard Series | 49/22 | 300/625 | 10/25 |
| 12" Standard Series | 57/25 | 300/625 | 12/30 |
| 14" Standard Series | 72/32 | 300/625 | 14/35 |
