Patriot Docks Straight Dock w/ Gray Aluminum Decking - MW
Patriot Docks Straight Dock with Gray Aluminum Decking
Patriot modular aluminum marine docks provide the ultimate in shoreline enjoyment. 12-in. deep aluminum truss frames are expertly crafted with welded and bolted connections. Patriot Docks uses 7/16 in. diameter aluminum chord rods, not 3/8 in. like most of their competitors. Pipe is all 1-1/2"" schedule 40 electro-galvanized steel, not lighter weight steel tubing. Patriot Dock's pipe brackets are extra long with two - not one - stainless steel set bolts. Patriot Docks have a limited Lifetime Warranty on aluminum frame and aluminum decking. Maximum span between supports is 16'. Side lip on frame to hide decking edge.
Gray Aluminum decking is the lightest, longest lasting, and most rigid style decking that Patriot Docks offers. The two tone, wood grain powder coat finish is very durable and looks great. Aluminum decking is wildly popular and comes highly recommended.
Standard post lengths at given dock lengths: <16' = 4' supports, 16'-32' = 6' supports, >32' = 8' supports.
Features:
- High truss work allows for more land on the support pipe creating very rigid structure
- 1-1/2″ i.d galvanized schedule 40 pipe axle
- Light weight removable decking
- High quality marine grade aluminum allows for maximum strength and durability
- Deck panels nest into frame
- 24″ diameter never-go-flat dock wheels
- Easy to install and remove
16' Straight Dock Kits Includes:
- (2) 4 x 8 Frames
- (4) 4 x 4 Deck Panels
- (1) End Rail
- (2) Post Brackets
- (2) 4' Posts
- (2) Foot Plates for Posts
- (2) Vinyl Caps for posts
- Nuts and Bolts
24' Straight Dock Kits Includes:
- (3) 4 x 8 Frames
- (6) 4 x 4 Deck Panels
- (1) End Rail
- (4) Post Brackets
- (2) 4' Posts
- (2) 6' Posts
- (4) Foot Plates for Posts
- (4) Vinyl Caps for posts
- Nuts and Bolts
32' Straight Dock Kits Includes:
- (4) 4 x 8 Frames
- (8) 4 x 4 Deck Panels
- (1) End Rail
- (4) Post Brackets
- (2) 4' Posts
- (2) 6' Posts
- (4) Foot Plates for Posts
- (4) Vinyl Caps for posts
- Nuts and Bolts
40' Straight Dock Kits Includes:
- (6) 4 x 8 Frames
- (12) 4 x 4 Deck Panels
- (2) End Rail
- (6) Post Brackets
- (2) 4' Posts
- (2) 6' Posts
- (2) 8' Posts
- (6) Foot Plates for Posts
- (6) Vinyl Caps for posts
- Nuts and Bolts
